used in mining industry titanium separation whole set flotation equipment repairing and protecting
Panzihua Longmang mining industry titanium separation whole set flotation equipment are both produced by North Mining Institute,
there are phosphoric acid etc. medium in the agentia in the process of titanium separation,there are abrasion and corrosion in the
process of using cell body,the area of pending-protection part is about 4500m2,we offer 2 sets of scheme earlier stage,
one set is making BD7052 flotation cell special repair compound anti wear corrosion resistant coatings scrape coating for
one time completely,the other set is doing anticorrosion for one time with BD407 corrosion resistant coatings first,
then use BD121 wear resistant ceramic adhesive to paste 3mm thickness abrasion resistant ceramic.
Finally the first party chooses the second scheme.
The construction technology of BD121 wear resistant ceramic adhesives:
1.Clean up the mineral powder,ore pulp in the cell body.
2.Polish and clean the cell body.
3.Configure BD407 corrosion resistant coating and scrape coating on the surface of cell body based on surface treatment uniformly.
4.Configure BD121 abrasion resistant ceramic adhesive,then scrape coating on the surface of the BD407 after initial curing.
5.Make the ceramic adhesive paste on the surface of cell body uniformly,then knock on it to be compacted with rubber hammer.
6.It can be used after curing for 24 hours.
Performance index£º
| Product model | physical state | Standard packing |
operation time limit (25¡æ) |
Curing time (25¡æ) |
Range of application |
| BD121 | paste | 5kg | 0.5h | 12h |
Used in the self-adhesion and each-adhesion between metal and ceramic etc materials. Especially used in the bonding of wear resistant ceramic tile on the ceiling and facade of the equipment which suffers ash powder scour and material scour or erosive wear. |
| Item | Color |
Density (g/cm3) |
Shear strength (kg/cm2) GB7124-2008 |
Impact strength (J/cm2) GB6328-1999 |
Tensile strength (kg/cm2) GB6329-2008 |
Compressive strength (Mpa) GB1041-2008 |
Working temperature £¨¡æ£© |
| BD121 wear resistant ceramic adhesives | white | 1.24 | 152 | 56 | 785 | 92.3 | -60-150 |
Application photos show:
